SAP Online Text Repository (OTR): SAP OTR Tcodes, Tables, Function and Translation

Dec 21, 2017 by Siva in ABAP Tutorials

What’s OTR in SAP ?

“The Online Text Repository (OTR) is a central storage location for texts, and provides services for editing and managing these texts.

The main task of the OTR is to support the creation and translation of texts. The OTR makes translation of texts possible. Terminology is more uniform and texts can easily be reused.

This means texts are of high quality right from the start. This also considerably reduces costs for text corrections, such as for spelling mistakes, inconsistent terminology, incorrect style, and so on. Terminology changes can be done from a central location.
The object itself is separated from the texts. Any changes to the object do not influence the texts, and the other way round. This means you can translate the texts independently of the object.” (1)

The OTR is currently supported by the following applications:

Web Dynpro for ABAP
Business Server Pages
Exception Builder
HTTP Services
Web Services
Enhancement Tools

Table of Contents

SAP OTR Tcodes

The main OTR Tcodes in SAP are:

SOTR_EDIT
SE63_OTR

SOTR_EDIT

The transaction code SOTR_EDIT is the Editor for OTR Texts. You can Display, Create and Change OTR Objects using this tcode.

To keep it simple, here a screenshot of what the SOTR_EDIT Transaction looks like:

SOTR_EDIT is the Editor for OTR Texts

SE63/ SE63_OTR

To just remember that the Standard SAP Transaction SE63 is the main transaction for Translation Editor.

To find OTR objects, navigate through
Other Texts > Object Type Selection (Object Groups) > A5 User Interface Texts > LOTR OTR Long Texts

The most Common SAP Function Modules

Here the list of the most useful SAP Function Modules for OTR:

SOTR_GET_TEXTS_WITH_KEYS
SOTR_GET_CONCEPT
SOTR_DELETE_CONCEPT
SOTR_OBJECT_GET_OBJECTS
SOTR_OBJECT_GET_OBJECTS
SOTR_CREATE_CONCEPT
OTR_TOOLS_GET_TEXT_VIA_ALIAS

SOTR_GET_TEXTS_WITH_KEYS

SOTR_GET_TEXTS_WITH_KEYS: Holen von Texten anhand der Concept ID und dem Kontext

function SOTR_GET_TEXTS_WITH_KEYS.
*"----------------------------------------------------------------------
*"*"Lokale Schnittstelle:
*"  IMPORTING
*"     VALUE(LANGU) TYPE  SYLANGU
*"     VALUE(CONTEXT) TYPE  SOTR_CNTXT
*"     VALUE(REFILL_WITH_SECONDARY_LANGU) TYPE  BAPIFLAG DEFAULT 'X'
*"     VALUE(REFILL_WITH_MASTER_LANGU) TYPE  BAPIFLAG DEFAULT ' '
*"     VALUE(FLAG_CONTEXT) TYPE  AS4FLAG OPTIONAL
*"     VALUE(FLAG_WITH_ALIAS) TYPE  AS4FLAG DEFAULT 'X'
*"  TABLES
*"      SOTR_TERMS STRUCTURE  SOTR_TERM
*"  EXCEPTIONS
*"      NO_ENTRY_FOUND
*"      LANGUAGE_MISSING
*"----------------------------------------------------------------------

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

function SOTR_GET_TEXTS_WITH_KEYS.

*"----------------------------------------------------------------------

*"*"Lokale Schnittstelle:

*" IMPORTING

*" VALUE(LANGU) TYPE SYLANGU

*" VALUE(CONTEXT) TYPE SOTR_CNTXT

*" VALUE(REFILL_WITH_SECONDARY_LANGU) TYPE BAPIFLAG DEFAULT 'X'

*" VALUE(REFILL_WITH_MASTER_LANGU) TYPE BAPIFLAG DEFAULT ' '

*" VALUE(FLAG_CONTEXT) TYPE AS4FLAG OPTIONAL

*" VALUE(FLAG_WITH_ALIAS) TYPE AS4FLAG DEFAULT 'X'

*" TABLES

*" SOTR_TERMS STRUCTURE SOTR_TERM

*" EXCEPTIONS

*" NO_ENTRY_FOUND

*" LANGUAGE_MISSING

*"----------------------------------------------------------------------

SOTR_GET_CONCEPT

The SAP Function module SOTR_GET_CONCEPT will Get all entries to an OTR concept.

Here the signature of SOTR_GET_CONCEPT:

function SOTR_GET_CONCEPT.
*"----------------------------------------------------------------------
*"*"Lokale Schnittstelle:
*"  IMPORTING
*"     REFERENCE(CONCEPT) LIKE  SOTR_HEAD-CONCEPT
*"  EXPORTING
*"     VALUE(HEADER) LIKE  SOTR_HEAD STRUCTURE  SOTR_HEAD
*"  TABLES
*"      ENTRIES STRUCTURE  SOTR_TEXT OPTIONAL
*"  EXCEPTIONS
*"      NO_ENTRY_FOUND
*"----------------------------------------------------------------------

1

2

3

4

5

6

7

8

9

10

11

12

function SOTR_GET_CONCEPT.

*"----------------------------------------------------------------------

*"*"Lokale Schnittstelle:

*" IMPORTING

*" REFERENCE(CONCEPT) LIKE SOTR_HEAD-CONCEPT

*" EXPORTING

*" VALUE(HEADER) LIKE SOTR_HEAD STRUCTURE SOTR_HEAD

*" TABLES

*" ENTRIES STRUCTURE SOTR_TEXT OPTIONAL

*" EXCEPTIONS

*" NO_ENTRY_FOUND

*"----------------------------------------------------------------------

SOTR_DELETE_CONCEPT

In order to Delete an OTR concept, you can use the standard Function SOTR_DELETE_CONCEPT.

The signature of SOTR_DELETE_CONCEPT is:

function SOTR_DELETE_CONCEPT.
*"----------------------------------------------------------------------
*"*"Lokale Schnittstelle:
*"  IMPORTING
*"     VALUE(CONCEPT) LIKE  SOTR_HEAD-CONCEPT
*"     VALUE(IN_UPDATE_TASK) TYPE  AS4FLAG OPTIONAL
*"     VALUE(FLAG_CHECK_USAGE) TYPE  AS4FLAG OPTIONAL
*"     VALUE(FLAG_CHECK_AUTHORITY) TYPE  AS4FLAG OPTIONAL
*"     VALUE(FLAG_CHECK_MASTER) TYPE  AS4FLAG OPTIONAL
*"     VALUE(LANGU) TYPE  SYLANGU DEFAULT SY-LANGU
*"     VALUE(FLAG_CORRECTION_ENTRY) TYPE  AS4FLAG OPTIONAL
*"  EXPORTING
*"     REFERENCE(FLAG_CANCELLED) TYPE  AS4FLAG
*"  EXCEPTIONS
*"      NO_ENTRY_FOUND
*"      TEXT_NOT_FOUND
*"      INVALID_PACKAGE
*"      TEXT_NOT_CHANGEABLE
*"      TEXT_ENQUEUED
*"      NO_CORRECTION
*"      PARAMETER_ERROR
*"----------------------------------------------------------------------

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

function SOTR_DELETE_CONCEPT.

*"----------------------------------------------------------------------

*"*"Lokale Schnittstelle:

*" IMPORTING

*" VALUE(CONCEPT) LIKE SOTR_HEAD-CONCEPT

*" VALUE(IN_UPDATE_TASK) TYPE AS4FLAG OPTIONAL

*" VALUE(FLAG_CHECK_USAGE) TYPE AS4FLAG OPTIONAL

*" VALUE(FLAG_CHECK_AUTHORITY) TYPE AS4FLAG OPTIONAL

*" VALUE(FLAG_CHECK_MASTER) TYPE AS4FLAG OPTIONAL

*" VALUE(LANGU) TYPE SYLANGU DEFAULT SY-LANGU

*" VALUE(FLAG_CORRECTION_ENTRY) TYPE AS4FLAG OPTIONAL

*" EXPORTING

*" REFERENCE(FLAG_CANCELLED) TYPE AS4FLAG

*" EXCEPTIONS

*" NO_ENTRY_FOUND

*" TEXT_NOT_FOUND

*" INVALID_PACKAGE

*" TEXT_NOT_CHANGEABLE

*" TEXT_ENQUEUED

*" NO_CORRECTION

*" PARAMETER_ERROR

*"----------------------------------------------------------------------

SOTR_OBJECT_GET_OBJECTS

In order to determining the vector to a category of OTR Object, you should use SOTR_OBJECT_GET_OBJECTS.

Here the signature of SOTR_OBJECT_GET_OBJETS:

function SOTR_OBJECT_GET_OBJECTS .
*"----------------------------------------------------------------------
*"*"Lokale Schnittstelle:
*"  IMPORTING
*"     VALUE(OBJECT_VECTOR) TYPE  SOTR_OBJID
*"  EXPORTING
*"     REFERENCE(OBJECTS) TYPE  SOTR_OBJECTS
*"  EXCEPTIONS
*"      OBJECT_NOT_FOUND
*"----------------------------------------------------------------------

1

2

3

4

5

6

7

8

9

10

function SOTR_OBJECT_GET_OBJECTS .

*"----------------------------------------------------------------------

*"*"Lokale Schnittstelle:

*" IMPORTING

*" VALUE(OBJECT_VECTOR) TYPE SOTR_OBJID

*" EXPORTING

*" REFERENCE(OBJECTS) TYPE SOTR_OBJECTS

*" EXCEPTIONS

*" OBJECT_NOT_FOUND

*"----------------------------------------------------------------------

SOTR_CREATE_CONCEPT

The standatd function to create an OTR Concept is Creating an OTR concept.

Here the signature of SOTR_CREATE_CONCEPT:

function SOTR_CREATE_CONCEPT.
*"----------------------------------------------------------------------
*"*"Lokale Schnittstelle:
*"  IMPORTING
*"     REFERENCE(PAKET) TYPE  SOTR_PACK
*"     REFERENCE(CREA_LAN) TYPE  SY-LANGU
*"     REFERENCE(ALIAS_NAME) TYPE  SOTR_ALIAS OPTIONAL
*"     REFERENCE(CATEGORY) TYPE  SOTR_CATY OPTIONAL
*"     REFERENCE(OBJECT) TYPE  TROBJTYPE
*"     VALUE(ENTRIES) TYPE  SOTR_TEXT_TT
*"     REFERENCE(FLAG_CORRECTION_ENTRY) TYPE  AS4FLAG OPTIONAL
*"     REFERENCE(IN_UPDATE_TASK) TYPE  BAPIFLAG OPTIONAL
*"     VALUE(CONCEPT_DEFAULT) TYPE  SOTR_TEXT-CONCEPT OPTIONAL
*"     VALUE(FLAG_COPY_TEXT) TYPE  BTFR_FLAG OPTIONAL
*"  EXPORTING
*"     VALUE(CONCEPT) TYPE  SOTR_TEXT-CONCEPT
*"     VALUE(NEW_ENTRIES) TYPE  SOTR_TEXT_TT
*"----------------------------------------------------------------------

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

function SOTR_CREATE_CONCEPT.

*"----------------------------------------------------------------------

*"*"Lokale Schnittstelle:

*" IMPORTING

*" REFERENCE(PAKET) TYPE SOTR_PACK

*" REFERENCE(CREA_LAN) TYPE SY-LANGU

*" REFERENCE(ALIAS_NAME) TYPE SOTR_ALIAS OPTIONAL

*" REFERENCE(CATEGORY) TYPE SOTR_CATY OPTIONAL

*" REFERENCE(OBJECT) TYPE TROBJTYPE

*" VALUE(ENTRIES) TYPE SOTR_TEXT_TT

*" REFERENCE(FLAG_CORRECTION_ENTRY) TYPE AS4FLAG OPTIONAL

*" REFERENCE(IN_UPDATE_TASK) TYPE BAPIFLAG OPTIONAL

*" VALUE(CONCEPT_DEFAULT) TYPE SOTR_TEXT-CONCEPT OPTIONAL

*" VALUE(FLAG_COPY_TEXT) TYPE BTFR_FLAG OPTIONAL

*" EXPORTING

*" VALUE(CONCEPT) TYPE SOTR_TEXT-CONCEPT

*" VALUE(NEW_ENTRIES) TYPE SOTR_TEXT_TT

*"----------------------------------------------------------------------

OTR_TOOLS_GET_TEXT_VIA_ALIAS

The Standard Function Module OTR_TOOLS_GET_TEXT_VIA_ALIAS will retrieve the text from Alias.

SAP OTR Tables Related

The main SAP OTR tables are:

SOTR_HEAD: Header Table for OTR Texts
SOTR_TEXT: Text Table in the OTR
OTR_COMM: OTR: Comment for Concept
OTR_VOTE: OTR: Voting Result
SOTR_ALIA: Global Alias Name Management in the OTR
SOTR_ALIAU: Global Alias Name Management in the OTR
SOTR_HEADU: Header Table for Strings in the OTR
SOTR_INDEX: Index of OTR Entries for Terminology
SOTR_LINK: Concaneted OTR Texts
SOTR_TEXTU: Text Table in the OTR with Strings
SOTR_USE: Where-Used List for OTR Texts
SOTR_USEU: Where-Used List for Strings in the OTR

Let’s focus on the main tables SOTR_HEAD and SOTR_TEXT.

SOTR_HEAD Table

The table SOTR_HEAD is Header Table for OTR Texts.
Note that the key for SOTR_HEAD is the CONCEPT ( Key for Logical Object in OTR ).

The List of fields of SOTR_HEAD are:

CONCEPT : Key for Logical Object in OTR
PAKET : Package
CREA_LAN : Language Key
TRALA_TYPE : OTR Translation Class
ALIAS_NAME : Unique Alias Name for OTR Concept
CREA_NAME : User Name
CREA_TSTUT : Timestamp (date and time) related to UTC (GMT)
CHAN_NAME : User Name
CHAN_TSTUT : Timestamp (date and time) related to UTC (GMT)
LST_IMPORT : Date data element for SYST
SYSTEM_ID : Name of SAP System
TRALA_VEC : Language Vector for Translation Administration
CATGY_VEC : Vector of Assigned Categories
OBJID_VEC : Vector of Object Types
TEXT_TYPE : Type of Referenced Texts

SOTR_TEXT Table

The Text of OTR can be found in SOTR_TEXT table (Text Table in the OTR).

For each entry in SOTR_TEXT, there is 3 keys:

CONCEPT: Key for Logical Object in OTR
LANGU: Language Key
OBJECT: Key for Physical Object in OTR

SAP OTR Translation

As OTR is finally a text, SAP offers a standard way to Internatinalize the text. Find also a custom ABAP report usefull to translate OTRs in an WebDynPro ABAP.

Check also

OTR Translation via Standard SAP Tcode

It is possible to translate WDY text elements via standard SAP transaction.

Open your Web Dynpro view you want to translate via SE80
Menu: Goto >> Object directory entry. You’ll see object, notice it.
Start transaction SE63
Menu: Translation >> ABAP Objects >> Transport Object
Type in your noticed object at field “Transport Entry of Object” and press Edit.
You’ll see ever single text under your paket entry.

Custom ABAP Code for OTR Translation for WDA (2)

Here the custom ABAP Code that can be used for OTR Transactions ( only OTRs used in WDA).
The following ABAP code is originally posted on SDN.

*&---------------------------------------------------------------------*
*& Report ZGGAR_WDA_OTR_TRANSLATE
*&
*& Inspired from: https://wiki.sdn.sap.com/wiki/display/WDABAP/OTR+Text+Translation+Tool+for+Web+Dynpro+ABAP
*&
*& Transaction: SOTR_EDIT   -> use it at your own (psycho) risks
*&
*& WDCA Web Dynpro Application Configuration
*& WDCC Web Dynpro Component Configuration
*& WDYA Web Dynpro Application
*& WDYC Controller (Web Dynpro)
*& WDYD Definition (Web Dynpro)
*& WDYV View (Web Dynpro)
*&---------------------------------------------------------------------*

REPORT zggar_wda_otr_translate.

INCLUDE: <color>.

TABLES: wdy_component.

CONSTANTS: g_display_mode    TYPE bapiflag VALUE 'D',
           g_translate_mode  TYPE bapiflag VALUE 'T'.

**********************************************************************
* Global Types Declaration *
**********************************************************************
TYPES: BEGIN OF gsty_wd_out_tab,
         btn_01         TYPE c LENGTH 10,   " Translate hyperlink
         btn_02         TYPE c LENGTH 10,   " Concept   hyperlink
         component_name TYPE wdy_component_name,
         view_name      TYPE wdy_view_name,
         src_language   TYPE i,
         tgt_language   TYPE i,
         not_translated TYPE i,
         row_color_tab  TYPE lvc_t_scol,
END OF gsty_wd_out_tab.

TYPES: gtty_wd_out_tab TYPE TABLE OF gsty_wd_out_tab.

TYPES: BEGIN OF gsty_wdy_cname_f4,
         component_name TYPE wdy_component_name,
         description    TYPE wdy_md_description,
END OF gsty_wdy_cname_f4.

TYPES: ty_t_langu  TYPE TABLE OF sy-langu.

**********************************************************************
* CLASS lcl_handle_events DEFINITION
**********************************************************************
*
**********************************************************************
CLASS lcl_handle_events DEFINITION.
  PUBLIC SECTION.
    METHODS:
      on_link_click
      FOR EVENT link_click OF cl_salv_events_table
      IMPORTING row column,

      on_double_click
      FOR EVENT double_click OF cl_salv_events_table
      IMPORTING row column.

    METHODS:
      open_worklist      IMPORTING i_row     TYPE salv_de_row
                                   i_column  TYPE salv_de_column,

      open_concepts      IMPORTING i_row     TYPE salv_de_row
                                   i_column  TYPE salv_de_column,

      check_translations IMPORTING i_langu   TYPE sy-langu
                                   it_langus TYPE ty_t_langu
                                   i_column  TYPE salv_de_column
                         RETURNING value(r_continue) TYPE xfeld.


ENDCLASS. "lcl_handle_events DEFINITION

**********************************************************************
* Global Data Declaration *
**********************************************************************
DATA: gt_wd_otr        TYPE gtty_wd_out_tab.
DATA: go_event_handler TYPE REF TO lcl_handle_events.

DATA: g_object_name    TYPE trobj_name,
      gt_sotr_usage    TYPE sotr_use_tt,
      gt_worklist      TYPE sotr_wrkls_tt,
      gt_texts         TYPE sotr_strings,
      g_context        TYPE sotr_cntxt.

DATA: gt_celltab       TYPE lvc_t_styl.

DATA: go_otr_class     TYPE REF TO cl_sotr_string_maintain.

FIELD-SYMBOLS: <fs_sotr_usage>  LIKE LINE OF gt_sotr_usage,
               <fs_worklist>    LIKE LINE OF gt_worklist,
               <fs_row_color>   TYPE lvc_s_scol.


**********************************************************************
* SELECTION SCREEN *
**********************************************************************

SELECTION-SCREEN: BEGIN OF BLOCK b1.
SELECT-OPTIONS: pcname FOR wdy_component-component_name OBLIGATORY.

PARAMETERS: p_srclan TYPE sy-langu MATCHCODE OBJECT h_t002 OBLIGATORY DEFAULT 'E'.
PARAMETERS: p_tgtlan TYPE sy-langu MATCHCODE OBJECT h_t002 OBLIGATORY DEFAULT 'F'.
*PARAMETERS: p_all    RADIOBUTTON GROUP trad DEFAULT 'X',
*            p_not_t  RADIOBUTTON GROUP trad,
*            p_trad   RADIOBUTTON GROUP trad.

SELECTION-SCREEN SKIP.

PARAMETERS: p_count  AS CHECKBOX DEFAULT 'X'.
*PARAMETERS: p_devcls TYPE sotr_pack DEFAULT 'ZMMO'.
SELECTION-SCREEN: END OF BLOCK b1.

**********************************************************************
* SEARCH HELP *
**********************************************************************
AT SELECTION-SCREEN ON VALUE-REQUEST FOR pcname-low.
* Create Search Help
  DATA: lt_wdy_component TYPE TABLE OF gsty_wdy_cname_f4.
  FIELD-SYMBOLS:<lw_wdy_component> TYPE gsty_wdy_cname_f4.

  SELECT * FROM wdy_component
           INTO CORRESPONDING FIELDS OF TABLE lt_wdy_component
           WHERE component_name IN pcname.

  LOOP AT lt_wdy_component ASSIGNING <lw_wdy_component>.
    SELECT SINGLE * FROM wdy_componentt
                    INTO CORRESPONDING FIELDS OF <lw_wdy_component>
                    WHERE component_name = <lw_wdy_component>-component_name
                      AND langu = sy-langu.
  ENDLOOP.

  CALL FUNCTION 'F4IF_INT_TABLE_VALUE_REQUEST'
    EXPORTING
      retfield    = 'COMPONENT_NAME'
      dynprofield = 'PCNAME'
      dynpprog    = sy-cprog
      dynpnr      = sy-dynnr
      value_org   = 'S'
    TABLES
      value_tab   = lt_wdy_component.

**********************************************************************
* Text Initialization *
**********************************************************************
INITIALIZATION.
  %_pcname_%_app_%-text = 'WD Component Name'.
  %_p_srclan_%_app_%    = 'Source Language'.
  %_p_tgtlan_%_app_%    = 'Destination Language'.
  %_p_count_%_app_%     = 'Count entries'.
*  %_p_all_%_app_%       = 'All texts'.
*  %_p_not_t_%_app_%     = 'Not translated'.
*  %_p_trad_%_app_%      = 'Translated'.
*  %_p_devcls_%_app_%   = 'Development class'.

**********************************************************************
* START of SELECTION *
**********************************************************************
START-OF-SELECTION.

  DATA: gr_table     TYPE REF TO cl_salv_table,
        gr_display   TYPE REF TO cl_salv_display_settings,
        gr_functions TYPE REF TO cl_salv_functions,
        gr_events    TYPE REF TO cl_salv_events_table,
        gr_columns   TYPE REF TO cl_salv_columns_table,
        gr_column    TYPE REF TO cl_salv_column_table,
        l_color      TYPE lvc_s_colo.

  FIELD-SYMBOLS:<lw_wd_otr> TYPE gsty_wd_out_tab.

** Initialisation
  g_context-last_rel = sy-saprl.

** R?cup?ration
  SELECT * FROM wdy_view
           INTO CORRESPONDING FIELDS OF TABLE gt_wd_otr
           WHERE component_name IN pcname
             AND version        =  'A'
             AND type           =  'CL_WDY_MD_VIEW'.

  LOOP AT gt_wd_otr ASSIGNING <lw_wd_otr>.
    <lw_wd_otr>-btn_01 = 'Translate'.
    <lw_wd_otr>-btn_02 = 'Concepts'.

    IF p_count IS NOT INITIAL.
      CONCATENATE <lw_wd_otr>-component_name '%' <lw_wd_otr>-view_name
             INTO g_object_name RESPECTING BLANKS.
*      CONDENSE g_object_name NO-GAPS.

      CALL FUNCTION 'SOTR_USAGE_READ'
        EXPORTING
          pgmid          = 'LIMU'
          object         = 'WDYV'
          obj_name       = g_object_name
        IMPORTING
          sotr_usage     = gt_sotr_usage
        EXCEPTIONS
          no_entry_found = 1
          error_in_pgmid = 2
          OTHERS         = 3.

      IF gt_sotr_usage[] IS NOT INITIAL.
        SELECT COUNT( * ) FROM sotr_text
                          INTO <lw_wd_otr>-src_language
                          FOR ALL ENTRIES IN gt_sotr_usage
                          WHERE concept = gt_sotr_usage-concept
                            AND langu   = p_srclan
*                            AND object =
                          .

        SELECT COUNT( * ) FROM sotr_text
                          INTO <lw_wd_otr>-tgt_language
                          FOR ALL ENTRIES IN gt_sotr_usage
                          WHERE concept = gt_sotr_usage-concept
                            AND langu   = p_tgtlan
*                            AND object =
                          .

        <lw_wd_otr>-not_translated = <lw_wd_otr>-src_language - <lw_wd_otr>-tgt_language.

        IF <lw_wd_otr>-not_translated <> 0.
          APPEND INITIAL LINE TO <lw_wd_otr>-row_color_tab ASSIGNING <fs_row_color>.

          IF <lw_wd_otr>-src_language > <lw_wd_otr>-tgt_language.
            <fs_row_color>-fname   = 'TGT_LANGUAGE'.
          ELSE.
            <fs_row_color>-fname   = 'SRC_LANGUAGE'.
          ENDIF.
          <fs_row_color>-color-col = col_negative.
          <fs_row_color>-color-int = 0.
          <fs_row_color>-color-inv = 0.
        ENDIF.
      ENDIF.

***    Source language: comptage des entr?es
*      CREATE OBJECT go_otr_class
*        EXPORTING
*          i_langu   = p_srclan
*          i_context = g_context
*          i_paket   = g_devclass
*          i_pgmid   = 'LIMU'
*          i_object  = 'WDYV'
*          i_objname = g_object_name.
*
*      REFRESH: gt_texts.
*      CALL METHOD go_otr_class->get_strings_for_object
*        IMPORTING
*          e_texts = gt_texts.
*
*      <lw_wd_otr>-src_language = LINES( gt_texts ).

    ENDIF.
  ENDLOOP.

* Create ALV table
  cl_salv_table=>factory( IMPORTING r_salv_table = gr_table
                          CHANGING  t_table      = gt_wd_otr ).

* Set zebra layout
  gr_display = gr_table->get_display_settings( ).
  gr_display->set_striped_pattern( cl_salv_display_settings=>true ).

* Display all standard function
  gr_functions = gr_table->get_functions( ).
  gr_functions->set_all( abap_true ).

* Set the column BTN_01 as a link to tranlate
  gr_columns = gr_table->get_columns( ).
  gr_column ?= gr_columns->get_column( 'BTN_01' ).
  l_color-col = '4'.
  l_color-int = '1'.
  l_color-inv = '0'.
  gr_column->set_color( l_color ).
  gr_column->set_cell_type( 5 ).
  gr_column ?= gr_columns->get_column( 'BTN_02' ).
  l_color-col = '4'.
  l_color-int = '1'.
  l_color-inv = '0'.
  gr_column->set_color( l_color ).
  gr_column->set_cell_type( 5 ).

* Source and target count
  gr_column ?= gr_columns->get_column( 'BTN_01' ).
  gr_column->set_short_text( 'Translate' ).
  gr_column ?= gr_columns->get_column( 'BTN_02' ).
  gr_column->set_short_text( 'Concepts' ).
  gr_column ?= gr_columns->get_column( 'SRC_LANGUAGE' ).
  gr_column->set_short_text( 'Src lang.' ).
  gr_column ?= gr_columns->get_column( 'TGT_LANGUAGE' ).
  gr_column->set_short_text( 'Trgt lang.' ).
  gr_column ?= gr_columns->get_column( 'NOT_TRANSLATED' ).
  gr_column->set_short_text( 'Not transl' ).
  gr_column->set_medium_text( 'Not translated' ).

* Color
  gr_columns->set_color_column( 'ROW_COLOR_TAB' ).

* Set event hadler
  gr_events = gr_table->get_event( ).
  CREATE OBJECT go_event_handler.
  SET HANDLER go_event_handler->on_link_click   FOR gr_events.
  SET HANDLER go_event_handler->on_double_click FOR gr_events.

* Set event hadler
  gr_table->display( ).

**********************************************************************
* CLASS lcl_handle_events IMPLEMENTATION
**********************************************************************
*
**********************************************************************
CLASS lcl_handle_events IMPLEMENTATION.
  METHOD on_link_click.
    CASE column.
      WHEN 'BTN_01'.
        CALL METHOD me->open_worklist( i_row = row
          i_column = column ).

      WHEN 'BTN_02'.
        CALL METHOD me->open_concepts( i_row = row
          i_column = column ).
    ENDCASE.
  ENDMETHOD.                    "on_link_click

  METHOD on_double_click.
    DATA: l_object_name  TYPE trobj_name.
    DATA: lw_wd_compview TYPE gsty_wd_out_tab.

    DATA: lt_langus      TYPE TABLE OF sy-langu.

    CASE column.
      WHEN 'SRC_LANGUAGE'.
        CALL METHOD me->open_worklist( i_row = row
          i_column = column ).

      WHEN 'TGT_LANGUAGE'    OR
           'NOT_TRANSLATED'.

        REFRESH: gt_worklist.

        LOOP AT gt_sotr_usage ASSIGNING <fs_sotr_usage>.
**        V?rification du texte traduit dans la langue cible
          REFRESH: lt_langus.
          SELECT langu FROM sotr_text
                       INTO TABLE lt_langus
                       WHERE concept = <fs_sotr_usage>-concept
                         AND ( langu = p_srclan
                            OR langu = p_tgtlan ).

          IF me->check_translations( i_langu   = p_tgtlan
                                     it_langus = lt_langus[]
                                     i_column  = column ) IS NOT INITIAL.
            CONTINUE.
          ENDIF.

          APPEND INITIAL LINE TO gt_worklist ASSIGNING <fs_worklist>.
          MOVE <fs_sotr_usage>-concept TO <fs_worklist>-concept.
          IF <fs_sotr_usage>-lfd_num IS INITIAL.
            <fs_sotr_usage>-lfd_num = 1.
          ENDIF.
          MOVE <fs_sotr_usage>-lfd_num TO <fs_worklist>-lfd_num.
        ENDLOOP.

*        CHECK gt_worklist[] IS NOT INITIAL.

        CALL FUNCTION 'SOTR_EDITOR_WORKLIST'
          EXPORTING
            edit_mode                  = g_translate_mode
            source_langu               = p_srclan
            target_langu               = p_tgtlan
          CHANGING
            worklist                   = gt_worklist[]
          EXCEPTIONS
            no_entry_found             = 1
            error_in_context           = 2
            error_in_replacement_term  = 3
            edit_mode_not_supported    = 4
            no_authorization           = 5
            internal_error             = 6
            error_in_transport_request = 7
            OTHERS                     = 8.

    ENDCASE.

  ENDMETHOD. "on_double_click

  METHOD open_worklist.
    DATA: l_object_name  TYPE trobj_name.
    DATA: lw_wd_compview TYPE gsty_wd_out_tab.

    READ TABLE gt_wd_otr INTO lw_wd_compview INDEX i_row.

    CONCATENATE lw_wd_compview-component_name '%' lw_wd_compview-view_name
           INTO l_object_name RESPECTING BLANKS.
*    CONDENSE l_object_name NO-GAPS.

    CALL FUNCTION 'SOTR_API_WB_TRANSLATE'
      EXPORTING
        source_langu               = p_srclan
        target_langu               = p_tgtlan
        pgmid                      = 'LIMU'
        object                     = 'WDYV'
        obj_name                   = l_object_name
      EXCEPTIONS
        no_entry_found             = 1
        internal_error             = 2
        no_authorization           = 3
        error_in_context           = 4
        user_cancelled             = 5
        error_in_transport_request = 6
        OTHERS                     = 7.
    IF sy-subrc <> 0.
      MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno
      WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4.
    ENDIF.
  ENDMETHOD.                    "open_worklist

  METHOD open_concepts.
    DATA: l_object_name        TYPE trobj_name.
    DATA: lw_wd_compview       TYPE gsty_wd_out_tab.
    DATA: ls_entry             TYPE sotr_entry,
          ls_entry_key         TYPE SOTR_KEY,
          ls_extry_text        TYPE sotr_textu,
          ls_object            TYPE sotr_objec,
          lv_subrc             TYPE sy-subrc.

    DATA: lt_sotr_trees        TYPE sotr_trees,
          ls_sotr_tree         LIKE LINE OF lt_sotr_trees.

    FIELD-SYMBOLS: <l_field>   TYPE ANY.

    READ TABLE gt_wd_otr INTO lw_wd_compview INDEX i_row.

    CONCATENATE lw_wd_compview-component_name '%' lw_wd_compview-view_name
           INTO l_object_name RESPECTING BLANKS.
*    CONDENSE l_object_name NO-GAPS.

    REFRESH: lt_sotr_trees.

    SELECT * FROM  sotr_use AS u JOIN sotr_text AS t
              ON   ( u~concept = t~concept )
                                 JOIN sotr_head AS f
               ON  ( f~concept = t~concept )
             INTO CORRESPONDING FIELDS OF TABLE lt_sotr_trees
            WHERE u~object   =    'WDYV'
              AND u~obj_name LIKE l_object_name
              AND u~lfd_num  =    '0001'
              AND t~langu    =    p_srclan
              AND t~flag_com =    space.

    CHECK lt_sotr_trees[] IS NOT INITIAL.

    CLEAR: ls_sotr_tree.
    CALL FUNCTION 'SOTR_F4_HELP'
      EXPORTING
        sotr_trees     = lt_sotr_trees
        display_mode   = 'PAKET'
      IMPORTING
*       entry_selected = l_entry_key
        tree           = ls_sotr_tree
      EXCEPTIONS
        no_entry_found = 1
        OTHERS         = 2.


*-- just call an insignificant routine to load the SAPLSOTR_EDIT
    PERFORM check_string    IN PROGRAM saplsotr_edit USING    ls_extry_text   " dummy
                                                              ls_object       " dummy
                                                     CHANGING lv_subrc        " dummy
                                                     IF FOUND.

    " version 7.40?
    PERform send_db_message IN PROGRAM saplsotr_edit using lv_subrc           " dummy
                                                           sy-langu
                                                     IF FOUND.

*    l_entry-concept    = '4F320C0245EF00EBE1008000C0A8BFA3'.
*    l_entry-langu      = 'E'.
*    l_entry-object     = 'WDYV'.
*    l_entry-lfd_num    = '0001'.
*    l_entry-paket      = 'ZHROM'.
*    l_entry-crea_name   = 'FRX30520'.
*    l_entry-crea_tstut = '20120208103729'.
*    l_entry-chan_name  = 'FRX30520'.
*    l_entry-chan_tstut = '20120208103839'.
*    l_entry-length     = '032'.
*    l_entry-text       = 'Age Structure Diagram'.

**  Now program SAPLSOTR_EDIT has been loaded into memory, let's hack into its global variables !!
    ASSIGN ('(SAPLSOTR_EDIT)G_DYNP_0100-RAD_T') TO <l_field>.
    IF <l_field> IS ASSIGNED.
      <l_field> = 'X'.         " required to set the SUBDYNPRO to '0205'  (short text)
    ENDIF.
    ASSIGN ('(SAPLSOTR_EDIT)GL_MODE') TO <l_field>.
    IF <l_field> IS ASSIGNED.
      <l_field> = 'M'.         " required to access MAINTAIN mode
    ENDIF.
    ASSIGN ('(SAPLSOTR_EDIT)G_LANGU') TO <l_field>.
    IF <l_field> IS ASSIGNED.
      <l_field> = p_srclan.    " required to avoid CHECK messages
    ENDIF.

    CLEAR: ls_entry.
    MOVE-CORRESPONDING ls_sotr_tree to ls_entry.

    PERFORM call_screen_200 IN PROGRAM saplsotr_edit USING ls_entry
                                                           'E'
                                                           '*'
                                                           '*'.

  ENDMETHOD.                    "open_worklist


  METHOD check_translations.
    CASE i_column.
      WHEN 'NOT_TRANSLATED'.
        READ TABLE it_langus TRANSPORTING NO FIELDS WITH KEY table_line = i_langu.
        IF sy-subrc = 0.      " traduit
          r_continue = 'X'.   " pas d'ajout ? la liste de travail
        ENDIF.

      WHEN 'TGT_LANGUAGE'.
        READ TABLE it_langus TRANSPORTING NO FIELDS WITH KEY table_line = i_langu.
        IF sy-subrc <> 0.     " pas traduit
          r_continue = 'X'.   " pas d'ajout ? la liste de travail
        ENDIF.

    ENDCASE.
  ENDMETHOD.                    "check_translations

ENDCLASS. "lcl_handle_events IMPLEMENTATION

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

422

423

424

425

426

427

428

429

430

431

432

433

434

435

436

437

438

439

440

441

442

443

444

445

446

447

448

449

450

451

452

453

454

455

456

457

458

459

460

461

462

463

464

465

466

467

468

469

470

471

472

473

474

475

476

477

478

479

480

481

482

483

484

485

486

487

488

489

490

491

492

493

494

495

496

497

498

499

500

501

502

503

504

505

506

507

508

509

510

511

512

513

514

515

516

517

518

519

520

521

522

523

524

525

526

527

528

529

530

531

532

533

534

535

536

*&---------------------------------------------------------------------*

*& Report ZGGAR_WDA_OTR_TRANSLATE

*&

*& Inspired from: https://wiki.sdn.sap.com/wiki/display/WDABAP/OTR+Text+Translation+Tool+for+Web+Dynpro+ABAP

*&

*& Transaction: SOTR_EDIT -> use it at your own (psycho) risks

*&

*& WDCA Web Dynpro Application Configuration

*& WDCC Web Dynpro Component Configuration

*& WDYA Web Dynpro Application

*& WDYC Controller (Web Dynpro)

*& WDYD Definition (Web Dynpro)

*& WDYV View (Web Dynpro)

*&---------------------------------------------------------------------*

REPORT zggar_wda_otr_translate.

INCLUDE: <color>.

TABLES: wdy_component.

CONSTANTS: g_display_mode TYPE bapiflag VALUE 'D',

g_translate_mode TYPE bapiflag VALUE 'T'.

**********************************************************************

* Global Types Declaration *

**********************************************************************

TYPES: BEGIN OF gsty_wd_out_tab,

btn_01 TYPE c LENGTH 10, " Translate hyperlink

btn_02 TYPE c LENGTH 10, " Concept hyperlink

component_name TYPE wdy_component_name,

view_name TYPE wdy_view_name,

src_language TYPE i,

tgt_language TYPE i,

not_translated TYPE i,

row_color_tab TYPE lvc_t_scol,

END OF gsty_wd_out_tab.

TYPES: gtty_wd_out_tab TYPE TABLE OF gsty_wd_out_tab.

TYPES: BEGIN OF gsty_wdy_cname_f4,

component_name TYPE wdy_component_name,

description TYPE wdy_md_description,

END OF gsty_wdy_cname_f4.

TYPES: ty_t_langu TYPE TABLE OF sy-langu.

**********************************************************************

* CLASS lcl_handle_events DEFINITION

**********************************************************************

*

**********************************************************************

CLASS lcl_handle_events DEFINITION.

PUBLIC SECTION.

METHODS:

on_link_click

FOR EVENT link_click OF cl_salv_events_table

IMPORTING row column,

on_double_click

FOR EVENT double_click OF cl_salv_events_table

IMPORTING row column.

METHODS:

open_worklist IMPORTING i_row TYPE salv_de_row

i_column TYPE salv_de_column,

open_concepts IMPORTING i_row TYPE salv_de_row

i_column TYPE salv_de_column,

check_translations IMPORTING i_langu TYPE sy-langu

it_langus TYPE ty_t_langu

i_column TYPE salv_de_column

RETURNING value(r_continue) TYPE xfeld.

ENDCLASS. "lcl_handle_events DEFINITION

**********************************************************************

* Global Data Declaration *

**********************************************************************

DATA: gt_wd_otr TYPE gtty_wd_out_tab.

DATA: go_event_handler TYPE REF TO lcl_handle_events.

DATA: g_object_name TYPE trobj_name,

gt_sotr_usage TYPE sotr_use_tt,

gt_worklist TYPE sotr_wrkls_tt,

gt_texts TYPE sotr_strings,

g_context TYPE sotr_cntxt.

DATA: gt_celltab TYPE lvc_t_styl.

DATA: go_otr_class TYPE REF TO cl_sotr_string_maintain.

FIELD-SYMBOLS: <fs_sotr_usage> LIKE LINE OF gt_sotr_usage,

<fs_worklist> LIKE LINE OF gt_worklist,

<fs_row_color> TYPE lvc_s_scol.

**********************************************************************

* SELECTION SCREEN *

**********************************************************************

SELECTION-SCREEN: BEGIN OF BLOCK b1.

SELECT-OPTIONS: pcname FOR wdy_component-component_name OBLIGATORY.

PARAMETERS: p_srclan TYPE sy-langu MATCHCODE OBJECT h_t002 OBLIGATORY DEFAULT 'E'.

PARAMETERS: p_tgtlan TYPE sy-langu MATCHCODE OBJECT h_t002 OBLIGATORY DEFAULT 'F'.

*PARAMETERS: p_all RADIOBUTTON GROUP trad DEFAULT 'X',

* p_not_t RADIOBUTTON GROUP trad,

* p_trad RADIOBUTTON GROUP trad.

SELECTION-SCREEN SKIP.

PARAMETERS: p_count AS CHECKBOX DEFAULT 'X'.

*PARAMETERS: p_devcls TYPE sotr_pack DEFAULT 'ZMMO'.

SELECTION-SCREEN: END OF BLOCK b1.

**********************************************************************

* SEARCH HELP *

**********************************************************************

AT SELECTION-SCREEN ON VALUE-REQUEST FOR pcname-low.

* Create Search Help

DATA: lt_wdy_component TYPE TABLE OF gsty_wdy_cname_f4.

FIELD-SYMBOLS:<lw_wdy_component> TYPE gsty_wdy_cname_f4.

SELECT * FROM wdy_component

INTO CORRESPONDING FIELDS OF TABLE lt_wdy_component

WHERE component_name IN pcname.

LOOP AT lt_wdy_component ASSIGNING <lw_wdy_component>.

SELECT SINGLE * FROM wdy_componentt

INTO CORRESPONDING FIELDS OF <lw_wdy_component>

WHERE component_name = <lw_wdy_component>-component_name

AND langu = sy-langu.

ENDLOOP.

CALL FUNCTION 'F4IF_INT_TABLE_VALUE_REQUEST'

EXPORTING

retfield = 'COMPONENT_NAME'

dynprofield = 'PCNAME'

dynpprog = sy-cprog

dynpnr = sy-dynnr

value_org = 'S'

TABLES

value_tab = lt_wdy_component.

**********************************************************************

* Text Initialization *

**********************************************************************

INITIALIZATION.

%_pcname_%_app_%-text = 'WD Component Name'.

%_p_srclan_%_app_% = 'Source Language'.

%_p_tgtlan_%_app_% = 'Destination Language'.

%_p_count_%_app_% = 'Count entries'.

* %_p_all_%_app_% = 'All texts'.

* %_p_not_t_%_app_% = 'Not translated'.

* %_p_trad_%_app_% = 'Translated'.

* %_p_devcls_%_app_% = 'Development class'.

**********************************************************************

* START of SELECTION *

**********************************************************************

START-OF-SELECTION.

DATA: gr_table TYPE REF TO cl_salv_table,

gr_display TYPE REF TO cl_salv_display_settings,

gr_functions TYPE REF TO cl_salv_functions,

gr_events TYPE REF TO cl_salv_events_table,

gr_columns TYPE REF TO cl_salv_columns_table,

gr_column TYPE REF TO cl_salv_column_table,

l_color TYPE lvc_s_colo.

FIELD-SYMBOLS:<lw_wd_otr> TYPE gsty_wd_out_tab.

** Initialisation

g_context-last_rel = sy-saprl.

** R?cup?ration

SELECT * FROM wdy_view

INTO CORRESPONDING FIELDS OF TABLE gt_wd_otr

WHERE component_name IN pcname

AND version = 'A'

AND type = 'CL_WDY_MD_VIEW'.

LOOP AT gt_wd_otr ASSIGNING <lw_wd_otr>.

<lw_wd_otr>-btn_01 = 'Translate'.

<lw_wd_otr>-btn_02 = 'Concepts'.

IF p_count IS NOT INITIAL.

CONCATENATE <lw_wd_otr>-component_name '%' <lw_wd_otr>-view_name

INTO g_object_name RESPECTING BLANKS.

* CONDENSE g_object_name NO-GAPS.

CALL FUNCTION 'SOTR_USAGE_READ'

EXPORTING

pgmid = 'LIMU'

object = 'WDYV'

obj_name = g_object_name

IMPORTING

sotr_usage = gt_sotr_usage

EXCEPTIONS

no_entry_found = 1

error_in_pgmid = 2

OTHERS = 3.

IF gt_sotr_usage[] IS NOT INITIAL.

SELECT COUNT( * ) FROM sotr_text

INTO <lw_wd_otr>-src_language

FOR ALL ENTRIES IN gt_sotr_usage

WHERE concept = gt_sotr_usage-concept

AND langu = p_srclan

* AND object =

.

SELECT COUNT( * ) FROM sotr_text

INTO <lw_wd_otr>-tgt_language

FOR ALL ENTRIES IN gt_sotr_usage

WHERE concept = gt_sotr_usage-concept

AND langu = p_tgtlan

* AND object =

.

<lw_wd_otr>-not_translated = <lw_wd_otr>-src_language - <lw_wd_otr>-tgt_language.

IF <lw_wd_otr>-not_translated <> 0.

APPEND INITIAL LINE TO <lw_wd_otr>-row_color_tab ASSIGNING <fs_row_color>.

IF <lw_wd_otr>-src_language > <lw_wd_otr>-tgt_language.

<fs_row_color>-fname = 'TGT_LANGUAGE'.

ELSE.

<fs_row_color>-fname = 'SRC_LANGUAGE'.

ENDIF.

<fs_row_color>-color-col = col_negative.

<fs_row_color>-color-int = 0.

<fs_row_color>-color-inv = 0.

ENDIF.

ENDIF.

*** Source language: comptage des entr?es

* CREATE OBJECT go_otr_class

* EXPORTING

* i_langu = p_srclan

* i_context = g_context

* i_paket = g_devclass

* i_pgmid = 'LIMU'

* i_object = 'WDYV'

* i_objname = g_object_name.

*

* REFRESH: gt_texts.

* CALL METHOD go_otr_class->get_strings_for_object

* IMPORTING

* e_texts = gt_texts.

*

* <lw_wd_otr>-src_language = LINES( gt_texts ).

ENDIF.

ENDLOOP.

* Create ALV table

cl_salv_table=>factory( IMPORTING r_salv_table = gr_table

CHANGING t_table = gt_wd_otr ).

* Set zebra layout

gr_display = gr_table->get_display_settings( ).

gr_display->set_striped_pattern( cl_salv_display_settings=>true ).

* Display all standard function

gr_functions = gr_table->get_functions( ).

gr_functions->set_all( abap_true ).

* Set the column BTN_01 as a link to tranlate

gr_columns = gr_table->get_columns( ).

gr_column ?= gr_columns->get_column( 'BTN_01' ).

l_color-col = '4'.

l_color-int = '1'.

l_color-inv = '0'.

gr_column->set_color( l_color ).

gr_column->set_cell_type( 5 ).

gr_column ?= gr_columns->get_column( 'BTN_02' ).

l_color-col = '4'.

l_color-int = '1'.

l_color-inv = '0'.

gr_column->set_color( l_color ).

gr_column->set_cell_type( 5 ).

* Source and target count

gr_column ?= gr_columns->get_column( 'BTN_01' ).

gr_column->set_short_text( 'Translate' ).

gr_column ?= gr_columns->get_column( 'BTN_02' ).

gr_column->set_short_text( 'Concepts' ).

gr_column ?= gr_columns->get_column( 'SRC_LANGUAGE' ).

gr_column->set_short_text( 'Src lang.' ).

gr_column ?= gr_columns->get_column( 'TGT_LANGUAGE' ).

gr_column->set_short_text( 'Trgt lang.' ).

gr_column ?= gr_columns->get_column( 'NOT_TRANSLATED' ).

gr_column->set_short_text( 'Not transl' ).

gr_column->set_medium_text( 'Not translated' ).

* Color

gr_columns->set_color_column( 'ROW_COLOR_TAB' ).

* Set event hadler

gr_events = gr_table->get_event( ).

CREATE OBJECT go_event_handler.

SET HANDLER go_event_handler->on_link_click FOR gr_events.

SET HANDLER go_event_handler->on_double_click FOR gr_events.

* Set event hadler

gr_table->display( ).

**********************************************************************

* CLASS lcl_handle_events IMPLEMENTATION

**********************************************************************

*

**********************************************************************

CLASS lcl_handle_events IMPLEMENTATION.

METHOD on_link_click.

CASE column.

WHEN 'BTN_01'.

CALL METHOD me->open_worklist( i_row = row

i_column = column ).

WHEN 'BTN_02'.

CALL METHOD me->open_concepts( i_row = row

i_column = column ).

ENDCASE.

ENDMETHOD. "on_link_click

METHOD on_double_click.

DATA: l_object_name TYPE trobj_name.

DATA: lw_wd_compview TYPE gsty_wd_out_tab.

DATA: lt_langus TYPE TABLE OF sy-langu.

CASE column.

WHEN 'SRC_LANGUAGE'.

CALL METHOD me->open_worklist( i_row = row

i_column = column ).

WHEN 'TGT_LANGUAGE' OR

'NOT_TRANSLATED'.

REFRESH: gt_worklist.

LOOP AT gt_sotr_usage ASSIGNING <fs_sotr_usage>.

** V?rification du texte traduit dans la langue cible

REFRESH: lt_langus.

SELECT langu FROM sotr_text

INTO TABLE lt_langus

WHERE concept = <fs_sotr_usage>-concept

AND ( langu = p_srclan

OR langu = p_tgtlan ).

IF me->check_translations( i_langu = p_tgtlan

it_langus = lt_langus[]

i_column = column ) IS NOT INITIAL.

CONTINUE.

ENDIF.

APPEND INITIAL LINE TO gt_worklist ASSIGNING <fs_worklist>.

MOVE <fs_sotr_usage>-concept TO <fs_worklist>-concept.

IF <fs_sotr_usage>-lfd_num IS INITIAL.

<fs_sotr_usage>-lfd_num = 1.

ENDIF.

MOVE <fs_sotr_usage>-lfd_num TO <fs_worklist>-lfd_num.

ENDLOOP.

* CHECK gt_worklist[] IS NOT INITIAL.

CALL FUNCTION 'SOTR_EDITOR_WORKLIST'

EXPORTING

edit_mode = g_translate_mode

source_langu = p_srclan

target_langu = p_tgtlan

CHANGING

worklist = gt_worklist[]

EXCEPTIONS

no_entry_found = 1

error_in_context = 2

error_in_replacement_term = 3

edit_mode_not_supported = 4

no_authorization = 5

internal_error = 6

error_in_transport_request = 7

OTHERS = 8.

ENDCASE.

ENDMETHOD. "on_double_click

METHOD open_worklist.

DATA: l_object_name TYPE trobj_name.

DATA: lw_wd_compview TYPE gsty_wd_out_tab.

READ TABLE gt_wd_otr INTO lw_wd_compview INDEX i_row.

CONCATENATE lw_wd_compview-component_name '%' lw_wd_compview-view_name

INTO l_object_name RESPECTING BLANKS.

* CONDENSE l_object_name NO-GAPS.

CALL FUNCTION 'SOTR_API_WB_TRANSLATE'

EXPORTING

source_langu = p_srclan

target_langu = p_tgtlan

pgmid = 'LIMU'

object = 'WDYV'

obj_name = l_object_name

EXCEPTIONS

no_entry_found = 1

internal_error = 2

no_authorization = 3

error_in_context = 4

user_cancelled = 5

error_in_transport_request = 6

OTHERS = 7.

IF sy-subrc <> 0.

MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno

WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4.

ENDIF.

ENDMETHOD. "open_worklist

METHOD open_concepts.

DATA: l_object_name TYPE trobj_name.

DATA: lw_wd_compview TYPE gsty_wd_out_tab.

DATA: ls_entry TYPE sotr_entry,

ls_entry_key TYPE SOTR_KEY,

ls_extry_text TYPE sotr_textu,

ls_object TYPE sotr_objec,

lv_subrc TYPE sy-subrc.

DATA: lt_sotr_trees TYPE sotr_trees,

ls_sotr_tree LIKE LINE OF lt_sotr_trees.

FIELD-SYMBOLS: <l_field> TYPE ANY.

READ TABLE gt_wd_otr INTO lw_wd_compview INDEX i_row.

CONCATENATE lw_wd_compview-component_name '%' lw_wd_compview-view_name

INTO l_object_name RESPECTING BLANKS.

* CONDENSE l_object_name NO-GAPS.

REFRESH: lt_sotr_trees.

SELECT * FROM sotr_use AS u JOIN sotr_text AS t

ON ( u~concept = t~concept )

JOIN sotr_head AS f

ON ( f~concept = t~concept )

INTO CORRESPONDING FIELDS OF TABLE lt_sotr_trees

WHERE u~object = 'WDYV'

AND u~obj_name LIKE l_object_name

AND u~lfd_num = '0001'

AND t~langu = p_srclan

AND t~flag_com = space.

CHECK lt_sotr_trees[] IS NOT INITIAL.

CLEAR: ls_sotr_tree.

CALL FUNCTION 'SOTR_F4_HELP'

EXPORTING

sotr_trees = lt_sotr_trees

display_mode = 'PAKET'

IMPORTING

* entry_selected = l_entry_key

tree = ls_sotr_tree

EXCEPTIONS

no_entry_found = 1

OTHERS = 2.

*-- just call an insignificant routine to load the SAPLSOTR_EDIT

PERFORM check_string IN PROGRAM saplsotr_edit USING ls_extry_text " dummy

ls_object " dummy

CHANGING lv_subrc " dummy

IF FOUND.

" version 7.40?

PERform send_db_message IN PROGRAM saplsotr_edit using lv_subrc " dummy

sy-langu

IF FOUND.

* l_entry-concept = '4F320C0245EF00EBE1008000C0A8BFA3'.

* l_entry-langu = 'E'.

* l_entry-object = 'WDYV'.

* l_entry-lfd_num = '0001'.

* l_entry-paket = 'ZHROM'.

* l_entry-crea_name = 'FRX30520'.

* l_entry-crea_tstut = '20120208103729'.

* l_entry-chan_name = 'FRX30520'.

* l_entry-chan_tstut = '20120208103839'.

* l_entry-length = '032'.

* l_entry-text = 'Age Structure Diagram'.

** Now program SAPLSOTR_EDIT has been loaded into memory, let's hack into its global variables !!

ASSIGN ('(SAPLSOTR_EDIT)G_DYNP_0100-RAD_T') TO <l_field>.

IF <l_field> IS ASSIGNED.

<l_field> = 'X'. " required to set the SUBDYNPRO to '0205' (short text)

ENDIF.

ASSIGN ('(SAPLSOTR_EDIT)GL_MODE') TO <l_field>.

IF <l_field> IS ASSIGNED.

<l_field> = 'M'. " required to access MAINTAIN mode

ENDIF.

ASSIGN ('(SAPLSOTR_EDIT)G_LANGU') TO <l_field>.

IF <l_field> IS ASSIGNED.

<l_field> = p_srclan. " required to avoid CHECK messages

ENDIF.

CLEAR: ls_entry.

MOVE-CORRESPONDING ls_sotr_tree to ls_entry.

PERFORM call_screen_200 IN PROGRAM saplsotr_edit USING ls_entry

'E'

'*'

'*'.

ENDMETHOD. "open_worklist

METHOD check_translations.

CASE i_column.

WHEN 'NOT_TRANSLATED'.

READ TABLE it_langus TRANSPORTING NO FIELDS WITH KEY table_line = i_langu.

IF sy-subrc = 0. " traduit

r_continue = 'X'. " pas d'ajout ? la liste de travail

ENDIF.

WHEN 'TGT_LANGUAGE'.

READ TABLE it_langus TRANSPORTING NO FIELDS WITH KEY table_line = i_langu.

IF sy-subrc <> 0. " pas traduit

r_continue = 'X'. " pas d'ajout ? la liste de travail

ENDIF.

ENDCASE.

ENDMETHOD. "check_translations

ENDCLASS. "lcl_handle_events IMPLEMENTATION

References & Sources:

Tagged with: WebdynPro

SAP and SAP logo are registered trademarks of SAP AG. Sap4tech.net is not associated with SAP AG.
We have made every effort to make sure provide relevant search results, use the content on this site at your own risk.

We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.
