SAP Production Order Tables: find the most important SAP Tables used for Production Orders.

SAP PO Tables, in this article, will be classified by topics including: AFKO, AFVC, Status, Operation, Routines, Confirmations, missing Parts Tables,  SAP CIM Order Tables.

As bonus, you will find some useful join condition to retrieve data of Production Order data for Standard SAP Tables.

SAP Production Order Tables

What’s Production Order in SAP ?

Production orders are a fundamental part of Production Planning and Control (PP) . PP is fully integrated in the Logistics (LO) component and has, among others, interfaces to

  • Sales and Distribution (SD)
  • Materials Management (MM)
  • Controlling (CO)

Source: Production Orders (PP-SFC)

Main SAP Production Order Tables

The main Production order tables name in sap are

  • AUFK Production order headers
  • AFKO Order header data PP orders
  • AFPO Order item

Check also SAP Production Orders Tcodes and SAP Planning Order Transactions

Join Between AUFK and AFPO

To retrieve Order Header from PP Production Order, join between

AUFK (Order header) and AFPO on field AUFNR

SAP PO Status tables

The main Production Order Status tables are:

  • JSTO Status profile
  • JEST Object status
  • TJ30 user status codes
  • TJ31 process control user status

How to find Status of SAP Production Order  ?

In order to find SAP Production Order Status make a join between
AUFK (Order header) & JEST (active Status) on OBJNR

Link between JEST and TJ31 is set on STSMAS and ESTAT .

Alternatively, you can use the SAP Standard BAPI to read Production Order status:

SAP Production Order: Operation Table AFVC …

The Production Order Operation can be found in the following Tables

  • AFVC Order operations
  • AFVV Quantities/dates/values in the operation
  • AFVU User fields of the operation

SAP Production Order:  SAP Routing Tables

The Routing for Production Orders tables are:

  • AFFL Work order sequence
  • AFFH PRT assignment data for the work order (routing)

The link between AFKO (Order header) & AFVC (order routing) is set on field AUFPL

Sap production order confirmation table

SAP Order Confirmations are stored in

  • AFRU (confirmation)

To retrieve the confirmation of a SAP Production Order;
join between  AFVC (order routing) and AFRU (confirmation) on : AUFPL & APLZL & PLNFL & VORN

Sap production order Tcode and Transaction

Find the list of the most important SAP Tcodes for SAP Production Orders and Planned Order in SAP PP in the following Post SAP Production Orders Tcodes.

Production Order Tables in SAP PP

SAP PP Confirmations for SAP Production Orders Tables

The following list is the SAP Tables for Production Orders Confirmation in SAP PP

SAP Production Order TablesDescription
AFFW       Goods movements with errors from confirmation
AFRC       Table of planned changes to conf.: Automatic
AFRD       Default values for collective confirmation
AFRH       Header information for confirmation pool
AFRP1     Table of planned changes to conf.: Automatic
AFRP2/3/4      Table of planned changes for confirmation: A/B/Data
AFRU       Order completion confirmations
AFWI       Subsequently posted goods movements for conf
TAFWD      CORU: Messages that are not interpreted
TCORD      Table for field-dependent check routines
TCORU      Parameters for order confirmations
TCORV      Table with Routines for structuring variable
TCORW      Confirmation: Window Control
TPARU      Control paralleled confirmation processes
TPRRU      Control table for process chain for confirmation
TPRRUT     Text table for process control of confirmation
TRUGS      User status caused by deviation

Source: Table name& field name for production order & operation confirmation

List of SAP PP Production Order Data Tables

The following list is the SAP Production Order Tables in SAP PP.

These SAP PO Tables stored all the PO Data:

SAP Production Order TablesDescription
AFBP       CIM order: Batch print requests
AFFL       Work order sequence
AFKO       Order header data PP orders
AFPO       Order item
AFVC       Operation within an order
AFVU       DB structure of the user fields of the opera
AFVV       DB structure of the quantities/dates/values
FAPW       Index of production-/issuing plant for production
ORDCOM     Communication control Operation download

SAP Print PP Tables

SAP Print PP Tables hnadles the output of PP Documents.

Print PP TablesDescription
T496P      Print PP documents: Determination of output
T496R      Print PP shop papers: Report control
T496T      SAP Print PP shop papers: Transaction control
T496V      PP Print: Default Value for Printing Online

SAP CIM Order Tables in PP

The following List contains Related SAP CIM Tables in PP.

SAP CIM Order TablesDescription
T496B      CIM order: Assigning document types to refer
T496D      CIM: Destination/lists/spool parameters per
T496F      CIM order: Form description of the list
T496K      CIM order: Entity table of possible table id
T496N      List descriptions for CIM order Table
T496ZCIM order: Table-controlled table access
TCO03CIM order: Texts for TCO01
TCO41 Default values for generating operation in CIM order
TCO09CIM order: Text IDs of objects in orders

SAP Missing Parts Tables

Here an other list of SAP PP Tables related to Production Order Process.

The main SAP Missing Parts Tables are:

SAP Missing Parts TablesDescription
TCOF        Profile for missing parts info system
TCOFF       Profile for Missing Parts Info System: Display
TCOFFT      Texts for Missing Parts Info System: Display
TCOFG       Profile for missing parts info system: Criteria
TCOFGT      Texts for Missing Parts Info System: Criteria
TCOFK       Texts for functions in milestones/trigger
TCOFS       Profile for Missing Parts Info System: Sort
TCOFST      Texts for Missing Parts Info System: Sort
TCOFT       Texts for Missing Parts Info System
TXPR1       XPRA control – missing parts info system
TXPR1       XPRA control – missing parts info system
FTIND      Missing parts index

Text & Customizing Tables for Production Order

In the next part, you will find the list to related SAP PP Production Order  Tables starting with T*.

In fact, this Tables’s List is more for customizing and Text Tables.

SAP Production Order TablesDescription
T024F      Production scheduler
T399X      Parameters dependent on order type
T441C      Profile – availability check
T441CT     Texts for Profile "Display Availability Check"
T490       Transactions PP – orders – order category
T024F      Production scheduler
T024F      Production scheduler
T399X      Parameters dependent on order type
T441C     Profile – availability check
T441CT    Texts for Profile "Display Availability Check"
T490       Transactions PP – orders – order category
TC32       Assigning subscreen to processing location
TC34        Allocating operation to object type for the
TC62        Sequence of detail screens when processing
TCO01       Sequence/operations control in logistics
TCO04       Table for controlling the screen sequence
TCO05       CUA status depending on panel & trans. type
TCO06       Exclusive functions for PP orders
TCO10       Valuation variant for order costing
TCO11       Control table for production orders – available
TCO12       Control table production orders – stock
TCO36       PP orders: Control table for calling up pop-
TCO43       PP-SFC order profile
TCO43T      Description of production scheduler profile
TCO60       Sequence keys for input facility and verification
TCO61       Sequence key for PP orders
TCO62       Defining screen sequences for input facility
TCO63       Sequence of detail screens when maintaining
TCODB       Database fields development class CO per order
TCOKO       Constants for PP orders
TCOKT       Account assignment categories for order
TCOP        Field selection profile
TCOPS       Field selection profile
TCOPT       Description of Profile for Field Selection
TRUG        Reason for variances in completion confirmation
TRUGT       Text describing the reason for a variance in
